产品介绍：可变焦电子透镜Focustunablelenses
该系列电子可变焦透镜是针对不同应用的焦距可调透镜的领先供应商。 无论是电动还是机械驱动，可调透镜相对于传统光学元件的优势都非常显着。 镜头可以在尺寸，调谐范围，传输范围或速度方面满足您的特定要求。 |
|
most popular focus tunable lenses:
Specifications
Product description
Fast electrically tunable lens
Size (ØxH)
30mm x 9.7mm
30mm x 20.7mm
42mm x 36mm
40mm x 11.9mm
35mm x 8mm
Clear aperture
10mm
10mm
10mm
16mm
20mm
Lens Type
Plano convex
Plano convex
(offset lens optional)
Plano convex + plano concave offset lens
Plano convex to plano concave
Plano convex to plano concave
Focal length range
From +20 to +140mm
From -600 to +170 mm
From -500 to +500 mm
From -500 to +333 mm
From -40 to +40mm
Refractive Index
1.300 or 1.559
1.300
1.300
1.300
1.300 or 1.559
Recommended
Documentation
The compact EL-3-10 lens was designed for OEM integration into optical systems for various applications. The working principle is based on the well-established shape-changing lens technology. The curvature of the lens is adjusted by applying an electrical current. Thereby, the focal length is tuned to a desired value within very few milliseconds. The lens architecture is “push pull” which means that the lens curvature is deflected from concave to convex. With actuators based on proven voice-coil technology, the EL-3-10 focus tunable lens is extremely reliable and robust, well suited even for applications in harsh environments over large temperature ranges.
EL-3-10
The following table summarizes the main specifications of the EL-3-10:
| Specifications | |
Dimensions (Ø x thickness) | 10 x 4 mm |
Clear aperture | 3mm |
Optical power | +/- 13 dpt (+/- 77 mm) |
Transmission wavelength (>94%) | 420 to 1600nm (VIS & NIR coating options) |
Response time (10/90% step), settling time | 1, 4 ms |
Wavefront error | <0.15/<0.15λ* |
Operating temperature | -20 to 65°C |
* Wavefront error provided in λ RMS @525nm with optical axis vertical / horizontal
Applications
Applications for Optotune's EL-3-10 are among others:
Microscopy
Biometric systems
Optical coherence tomography (OCT)
Laser illumination
Laser shows
Design faster and more compact optical systems without complex mechanics using the electrically focus tunable lens EL-10-30-TC. By applying a current, the focal length of the 10 mm aperture lens can be tuned to a specific value in milliseconds. Thanks to an integrated temperature sensor and characterization data, the lens can be driven to precise focal powers using Optotune's lens driver 4. The EL-10-30-TC is available with two broadband coating options, VIS for 400-700nm and NIR for 700-1100nm.
EL-10-30-TC
The following table summarizes the main specifications of the compact EL-10-30-TC:
| Standard products | Tuningrange | Refractiveindex | Cover glass coating | Wavefront error* |
EL-10-30-TC-VIS-12D | +120 to +50 mm +8.3 to +20 dpt | 1.30 | 400 - 700nm | <0.25 / <0.60 λ |
EL-10-30-TC-NIR-12D | +120 to +50 mm | 1.30 | 700 - 1100nm | <0.25 / <0.60 λ |
* Wavefront error provided in λ RMS @525nm with optical axis vertical / horizontal
Applications
Applications for Optotune's EL-10-30-TC are among others:
Microscopy
Atom trapping
Optical coherence tomography (OCT)
Laser shows
