产品介绍:ultra-lownoiseamplifier超低噪声放大器
Our range of cryogenic amplifiers operates from 0.3 GHz all the way to 115 GHz.
产品联系:伽太科技,sales@gamtic.com,185 0219 3480.
Low Noise Factory专注于超低噪声的放大器,隔离器,频率覆盖1-115GHz,有超低温低噪声放大器和工业级温度放大器,封装有同轴和波导形式,产品包括:
1 1-29GHz低温学、低噪声系数放大器
2 4-8GHz超低噪声系数LNA, NF=0.45, SMA接头
3 6-20GHz超低噪声系数LNA, NF=0.9dB
4 28-52GHz超低噪声系数LNA, NF=2.8dB,WR-22接口
5 45-77GHz超低噪声系数LNA, NF=A1.8dB, WR-15
6 65-115GHz超低噪声系数LNA, NF=3.5dB, WR-10接口
LNF-LNC65_115WA LNF-LNC28_52WB LNF-LNC1.5_3.5A
Our room temperature amplifiers operates from 1 GHz all the way up to 115 GHz.
LNF-LNR23_42WB LNF-LNR65_115WB LNF-LNR45_77WA
RF bandwidth: 65-115 GHz
Noise Temperature: 28 K typical
Noise Figure: 0.40 dB typical
Gain: 23 dB
DC-power: Vd=1.00 V, Id=7 mA
One gate and one drain supply only
RF-connectors: WR10, UG387/U
DC-connector: 9-pin female Nano-D
LNF-LNC65_115WA is an ultra-low noise cryogenic amplifier operating in the 65-115 GHz frequency range. The LNA is packaged in a waveguide module using industry standard WR10 and Nano-D connectors.
The lightweight gold plated aluminum module measures 14.92*24.00*20.75 mm excluding the connectors. MMIC technology ensures reliable and repeatable unit-to-unit result.
产品联系:伽太科技,sales@gamtic.com,185 0219 3480.
RF bandwidth: 65-115 GHz
Noise Temperature: 310 K typical
Noise Figure: 3.2 dB typical
Gain: 26 dB
DC-power: Vd=1.50 V, Id=35 mA
One gate and one drain supply only
RF-connectors: WR10, UG-387/U
DC-connector: 9-pin female Nano-D
LNF-LNR65_115WB is an ultra-low noise amplifier operating in the 65-115 GHz frequency range. The LNA is packaged in a waveguide module using industry standard WR10 and Nano-D connectors. The lightweight gold plated aluminum module measures 14.92*24.00*20.75 mm. MMIC technology ensures reliable and repeatable unit-to-unit result.
RF bandwidth: 45-77 GHz
Noise Temperature: 217 K typical
Noise Figure: 2.4 dB typical
Gain: 34 dB
DC-power: Vd=1.80 V, Id=35 mA
One gate and one drain supply only
RF-connectors: WR15
DC-connector: 9-pin female Nano-D
LNF-LNR45_77WA is an ultra-low noise amplifier operating in the 45-77 GHz frequency range. The LNA is packaged in a waveguide module using industry standard WR15 and Nano-D connectors. The lightweight gold plated aluminum module measures 16.63*26.55*19.20 mm. MMIC technology ensures reliable and repeatable unit-to-unit result.
RF bandwidth: 6-20 GHz
Noise Temperature: 62 K typical
Noise Figure: 0.85 dB typical
Gain: 33 dB
DC-power: Vd=2.00 V, Id=47 mA
One gate and one drain supply only
RF-connectors: female SMA
DC-connector: 9-pin female Nano-D
LNF-LNR6_20A is an ultra-low noise amplifier operating in the 6-20 GHz frequency range. The LNA is packaged in a coaxial module using industry standard SMA and Nano-D connectors. The lightweight gold plated aluminum module measures 22*19.6*7.8 mm excluding the connectors. MMIC technology ensures reliable and repeatable unit-to-unit result.
RF bandwidth: 10-30 GHz
Noise Temperature: 105 K typical
Noise Figure: 1.35 dB typical
Gain: 27 dB
DC-power: Vd=1.50 V, Id=29 mA
One gate and one drain supply only
RF-connectors: 2.92 mm
DC-connector: 9-pin female Nano-D
LNF-LNR10_30A is an ultra-low noise amplifier operating in the 10-30 GHz frequency range. The LNA is packaged in a coaxial module using industry standard 2.92 mm and Nano-D connectors. The lightweight gold plated aluminum module measures 17.80*15.15*6.80 mm excluding the connectors. MMIC technology ensures reliable and repeatable unit-to-unit result.
RF bandwidth: 28-52 GHz
Noise Temperature: 10 K typical
Noise Figure: 0.15 dB typical
Gain: 34 dB
DC-power: Vd=1.00 V, Id=10 mA
One gate and one drain supply only
RF-connectors: WR22, UG599/U
DC-connector: 9-pin female Nano-D
LNF-LNC28_52WB is an ultra-low noise cryogenic amplifier operating in the 28-52 GHz frequency range. The LNA is packaged in a waveguide module using industry standard WR22 and Nano-D connectors.
The lightweight gold plated aluminum module measures 28.0*19.52*19.2 mm excluding the connectors. MMIC technology ensures reliable and repeatable unit-to-unit result.
