库存数量：
产品介绍：CustomMMIC提供衰减混频放大等等mmics产品，DC-50GHz
Custom MMIC 低噪声放大器 分布式放大器 功率放大器 驱动放大器
联系伽太科技 sales@gamtic.com，185 0219 3480
Custom MMIC 低噪声放大器 | ||||||||||
| Part Number | S-Parameters | Package | Frequency (GHz) | Gain (dB) | Noise Figure (dB) | Bias Current (mA) | Bias Voltage (V) | OIP3 (dBm) | Output p1dB (dBm) | Output Psat (dBm) |
| CMD119P3 | S2P | 3x3 mm QFN | 5-9 | 22 | 1.2 | 30 | 3.6 | 21 | 11 | 13 |
| CMD132 | S2P | DIE | 5-11 | 23 | 1.4 | 30 | 3.6 | 22 | 10 | 13 |
| CMD132P3 | S2P | 3x3 mm QFN | 5-11 | 21 | 1.4 | 30 | 3.6 | 22 | 10 | 13 |
| CMD157 | S2P | DIE | 6-18 | 26 | 1.5 | 52 | 3 | 23 | 11 | 13.5 |
| CMD157P3 | S2P | 3x3 mm QFN | 6-18 | 26 | 1.5 | 52 | 3 | 23 | 11 | 13.5 |
| CMD159 | S2P | DIE | 10-17 | 26 | 1.1 | 29 | 3/1.5 | 14 | 4 | 10 |
| CMD160 | S2P | DIE | 17 - 25 | 26.5 | 1.4 | 26 | 3/1.5 | 16 | 8 | 11 |
| CMD161 | S2P | DIE | 10-14 | 19 | 1.05 | 20 | 3/1.5 | 5 | 12 | |
| CMD162 | S2P | DIE | 26 - 34 | 22 | 1.7 | 25 | 2 | 14 | 7 | 9 |
| CMD163 | S2P | DIE | 17 - 27 | 24 | 1.3 | 120 | 8/3 | 26 | 19 | 20 |
| CMD167 | S2P | DIE | 10-17 | 15 | 2 | 55 | 3 | 24 | 11 | 13 |
| CMD167P3 | S2P | 3x3 mm QFN | 8-16 | 16 | 1.8 | 50 | 3 | 23 | 11 | 13 |
| CMD185P3 | S2P | 3x3 mm QFN | 4-8 | 15.5 | 1.9 | 75 | 4 | 29 | 15 | 17 |
| CMD186P3 | S2P | 3x3 mm QFN | 6-11 | 18.5 | 2.1 | 78 | 5 | 28 | 17 | 20 |
| CMD188 | S2P | DIE | 26 - 34 | 20 | 1.4 | 20 | 2/2 | 15 | 6 | 8 |
| CMD189P3 | S2P | 3x3 mm QFN | 10-14 | 19 | 1.4 | 20 | 1.5/1.5 | 13 | 4 | 7 |
| CMD190 | S2P | DIE | 33 - 45 | 19 | 2.1 | 25 | 2/2 | 13 | 4 | 7 |
| CMD193P3X4 | S2P | 3x4 mm QFN | 5-11 | 21 | 1.4 | 30 | 3.6 | 22 | 10 | 13 |
| CMD194C3 | S2P | 3x3 mm QFN | 6-20 | 20 | 2 | 120 | 4 | 26 | 15.5 | 16.5 |
Custom MMIC分布式放大器 | ||||||||||
| Part Number | S-Parameters | Package | Frequency (GHz) | Gain (dB) | Noise Figure (dB) | Bias Current (mA) | Bias Voltage (V) | OIP3 (dBm) | Output p1dB (dBm) | Output Psat (dBm) |
| CMD164 | S2P | DIE | DC - 30 GHz | 12 | 2.4 | 67 | 8/3 | 26 | 15 | 18 |
| CMD165 | S2P | DIE | 2 - 30 GHz | 12 | 2.4 | 67 | 8/3 | 26 | 15.5 | 18 |
| CMD173 | S2P | DIE | DC - 20 GHz | 15 | 2 | 78 | 8/3 | 28 | 18 | 20 |
| CMD173P4 | S2P | 4x4 mm QFN | DC - 20 GHz | 15 | 2 | 78 | 8/3 | 28 | 18 | 20 |
| CMD192 | S2P | DIE | DC - 20 GHz | 19.5 | 1.9 | 170 | 8/-1 | 31 | 24.5 | 26 |
| CMD192C5 | S2P | 5x5 mm QFN | DC - 20 GHz | 19.5 | 1.9 | 200 | 8/-1 | 31 | 25 | 27 |
| CMD197 | S2P | DIE | 1 - 24 GHz | 16 | 2.5 | 225 | 8 | 32 | 22 | 24 |
| CMD201 | S2P | DIE | DC - 20 | 12 | 3.4 | 400 | 10/-0.55/5 | 38 | 29 | 30 |
| CMD206 | S2P | DIE | DC - 50 | 11 | 3.5 | 32 | 4/3 | 22 | 12 | 14.5 |
Custom MMIC 功率放大器 | ||||||||||
| Part Number | S-Parameters | Package | Frequency (GHz) | Gain (dB) | Noise Figure (dB) | Bias Current (mA) | Bias Voltage (V) | OIP3 (dBm) | Output p1dB (dBm) | Output Psat (dBm) |
| CMD169P4 | S2P | 4x4 mm QFN | 5-7 | 19 | 6.5 | 375 | 7/3 | 37 | 28.4 | 29.4 |
| CMD170P4 | S2P | 4x4 mm QFN | 7.5 - 9 | 30 | 6.5 | 365 | 7/3 | 34 | 28.3 | 29 |
| CMD171P4 | S2P | 4x4 mm QFN | 9.5 - 11 | 21 | 6.5 | 380 | 7/3 | 35 | 28.4 | 29 |
| CMD184 | S2P | DIE | 0.5 - 20 | 13 | 700 | 28/-3.8/10 | 42 | 34.5 | 36.5 | |
| CMD216 | S2P | DIE | 14 - 18 | 16 | 550 | 28/-3.4 | 43 | 37 | 38 | |
| CMD217 | S2P | DIE | 28 - 32 | 20 | 580 | 28/-3.4 | 41 | 36.7 | 39.3 | |
Custom MMIC 驱动放大器 | ||||||||||
| Part Number | S-Parameters | Package | Frequency (GHz) | Gain (dB) | Noise Figure (dB) | Bias Current (mA) | Bias Voltage (V) | OIP3 (dBm) | Output p1dB (dBm) | Output Psat (dBm) |
| CMD158P3 | S2P | 3x3 mm QFN | 6-14 | 19.5 | 4 | 95 | 5 | 26.5 | 19.5 | 20.5 |
| CMD158C4 | S2P | 4x4 mm QFN | 6-16 | 21 | 4 | 95 | 5 | 26 | 20 | 21 |
| CMD166 | S2P | DIE | 20 - 40 | 9 | 4.5 | 76 | 4 | 27 | 17 | 18 |
| CMD187 | S2P | DIE | 2-20 | 22.5 | 6 | 115 | 3/2 | 29 | 14 | 16 |
| CMD187C4 | S2P | 4x4 mm QFN | 2-20 | 22.5 | 6 | 115 | 3/2 | 29 | 13 | 15 |
| CMD191C4 | S2P | 4x4 mm QFN | 4-10 | 20 | 4.5 | 123 | 5 | 30 | 21.5 | 22.5 |
| CMD199 | S2P | DIE | 26 - 35 | 15 | 3.5 | 72 | 5 | 24.5 | 19.5 | 21.5 |
| CMD200 | S2P | DIE | 9-13 | 15.5 | 3.25 | 38 | 5 | 20.5 | 15.5 | 17 |
| CMD207 | S2P | DIE | 20 - 40 | 35 | 5.5 | 270 | 4/3 | 29 | 18.5 | 21 |
