RF放大器

ADI公司的RF IC覆盖整个RF信号链，提供1000多款产品来满足各种RF系统设计需求。从业界领先的RF功能块到高度集成的多功能解决方案，我们的RF IC提供高性能并且简化了无线系统的设计。我们的RF IC配合我们世界领先的转换器，并且通过广泛的免费工具、在线支持社区和Circuits from the Lab®参考电路提供支持。

产品子分类

驱动放大器
RF/IF差分放大器
增益模块
低噪声放大器
功率放大器
RF放大器偏置控制器
宽带分布式放大器

产品选型表

All RF Amplifiers

Part#	RF Primary Function	Freq Response RF (min) (Hz)	Gain (typ) (dB)	Freq Response RF (max) (Hz)	OIP3 (typ) (dBm)	OP1dB (typ) (dBm)	Device Match	Vsupply (typ) (V)	Isupply (typ) (A)	US Price 100 to 499 ($ US)
HMC998APM5E	Power Amp	-	-	-	-	-	-	-	-	-
HMC998A-Die	Power Amp	0.1G	12	22G	41	31	Internal	15	500m	$211.82
HMC907APM5E	Power Amp	-	-	-	-	-	-	-	-	-
HMC907A-Die	Power Amp	-	-	-	-	-	-	-	-	-
HMC1022A-Die	Driver Amp, Wideband Distributed Amps	0	12	48G	32	22	-	-	150m	-
HMC716A	LNA	3.1G	18	3.9G	33	19	Internal	-	65m	-
HMC994APM5E	Power Amp	-	-	-	-	-	-	-	-	-
HMC994A-Die	Power Amp	0	14	30G	36	28	Internal	10	250m	$152.02
HMC943A	Power Amp	24G	22	34G	40	32	Internal	5.5	1.3	-
HMC8500	GaN Power Amp, Power Amp	10m	16	2.8G	50	-	External	28	100m	$84.00
HMC7950	LNA	2G	15	28G	26	16	-	5	64m	$137.68
HMC7885	Power Amp	2G	21	6G	53	44	Internal	28	-	-
HMC7748	Power Amp Module	2G	58	6G	48	38	-	-	-	-
HMC5805A	Driver Amp, Wideband Distributed Amps	0	11.5	40G	29	24.5	Internal	10	175m	$103.04
HMC392ALC4	LNA	3.5G	17	8G	34.5	19	Internal	5	61	$51.55
HMC392A-Die	LNA	3.5G	17.2	7G	32.5	19	Internal	5	59m	$43.20
HMC-C582	Power Amp Module	10M	24	20G	30	24	Internal	15	690m	-
HMC8114	GaN Power Amp, Power Amp	5.8G	68	18G	52	45	Internal	48	-	-
HMC7891	Limiting Amplifier Module	2G	48	18G	-	11	Internal	8	300m	-
HMC717A	LNA	4.8G	14.5	6G	29.5	18	Internal	-	73m	$6.70
HMC1114	GaN Power Amp, Power Amp	2.7G	33	3.8G	44	-	Internal	28	150m	$84.00
HMC952A	Power Amp	8G	30.5	14G	43	34	Internal	6	1400m	$31.35
HMC8410LP2FE	LNA	10m	18	10G	31.5	21	Internal	5	65m	$29.86
HMC8410-Die	LNA	10m	18	10G	31.5	20.5	Internal	5	65m	$32.85
HMC8402-Die	LNA	2G	13.5	30G	26	21	Internal	7	68m	$114.67
HMC8401-Die	LNA	0	14.5	28G	26	16.5	Internal	7.5	60m	$110.05
HMC8113	GaN Power Amp, Power Amp	2G	85	6G	57	47.5	Internal	220	-	-
HMC589A	Gain Block	0	21	4G	33	19	Internal	-	82m	$2.50
HMC1132	Power Amp	27G	22	32G	35	30	Internal	6	600m	$62.03
HMC1121	Power Amp	5.5G	27	8.5G	44	36	Internal	7	2200m	$57.20
HMC8400-Die	LNA	2G	14	30G	26.5	16	Internal	5	67m	$102.61
ADL5726	LNA	21.2G	24.7	23.6G	1	-8	Internal	3.3	92.4m	$11.89
ADL5725	LNA	17.7G	27.8	19.7G	-1.5	-11.5	Internal	3.3	108m	$11.89
ADL5724	LNA	12.7G	26.4	15.4G	2	-8	Internal	3.3	109.7m	$11.89
ADL5723	LNA	10.1G	24.5	11.7G	2.2	-10	Internal	3.3	109.1m	$11.89
ADL5721	LNA	5.9G	25.9	8.5G	4	-10.6	Internal	3.3	86.5m	$11.89
HMC930A-Die	Power Amp, Wideband Distributed Amps	0	13	40G	33.5	22	Internal	10	175m	$160.00
HMC1099	GaN Power Amp, Power Amp	0.01G	18.5	1.1G	47	-	Internal	28	100m	$77.00
HMC1144-Die	Power Amp	40G	19	70G	28	21	Internal	4	320m	$219.00
HMC8142	Driver Amp, Power Amp	81G	21	86G	29	25	Internal	4	450m	$136.04
HMC7543	Driver Amp, Power Amp	71G	21.5	76G	30	25	Internal	4	450m	$136.04
HMC1131	Driver Amp	24G	22	35G	35	24	Internal	5	225m	$41.75
HMC7229LS6	Power Amp	37G	24	40G	40	31.5	Internal	-	1200m	$48.75
HMC7229-Die	Power Amp	33G	24.5	40G	39	30.5	-	-	1.2	$43.46
HMC1127	LNA, Wideband Distributed Amps	2G	14	50G	22	12	Internal	5	65m	$131.00
HMC1126	LNA, Wideband Distributed Amps	2G	11	50G	28	15	Internal	5	66m	$119.00
hmc906a-die	Power Amp	27.3G	24	33G	41.5	32	Internal	6	1200m	$58.17
HMC637ALP5	Power Amp, Wideband Distributed Amps	0G	13	6G	44	29	Internal	12	400m	$98.52
HMC637A-Die	Power Amp, Wideband Distributed Amps	0G	14	6G	40	28	Internal	12	400m	$115.10
HMC788A	Gain Block	0M	14	10G	33	20	Internal	5	76m	$11.30
HMC7441	Power Amp	27.5G	23	31.5G	38	34	Internal	6	1000m	-
HMC7149-Die	GaN Power Amp, Power Amp	6G	19	18G	39.5	-	Internal	28	680	$394.44
HMC7327	GaN Power Amp, Power Amp	2.7G	26	3.5G	-	-	Internal	32	1400m	-
ADL5611	Gain Block	30M	22.2	6G	38.5	21	Internal	5	91m	-
ADL5610	Gain Block	30M	18.4	6G	38.4	20.6	Internal	5	91m	-
HMC7357	Power Amp	5.5G	29	8.5G	41.5	34.5	Internal	8	1200m	$44.16
HMC1087F10	GaN Power Amp, Power Amp	2G	11	20G	44	-	Internal	38	850m	$443.30
HMC1087-Die	GaN Power Amp, Power Amp	2G	11	20G	44	-	Internal	28	850m	$359.26
HMC1086F10	GaN Power Amp, Power Amp	2G	22	6G	48	-	Internal	28	1100m	$434.50
HMC1086-Die	GaN Power Amp, Power Amp	-	-	-	-	-	-	-	-	$329.94
HMC1082	Driver Amp	5.5G	22	18G	35	24	Internal	5	220m	$21.21
ADL5545	Gain Block	30M	24.1	6G	36.4	18.1	Internal	5	56m	-
ADL5544	Gain Block	30M	17.4	6G	34.9	17.6	Internal	5	55m	-
HMC6981	Power Amp	15G	26	20G	43.5	33.5	External	6	1100m	$44.39
HMC6980	Wideband Distributed Amp Module	0.01G	12	20G	28	28	Internal	12	345m	-
HMC3587	Gain Block	4G	14.5	10G	25	11	Internal	5	44m	$13.98
HMC1049LP5E	LNA, Wideband Distributed Amps	0.3G	15	20G	29	15	Internal	7	70m	$92.69
HMC1049-Die	LNA, Wideband Distributed Amps	0.3G	16	19G	27	15	Internal	7	70m	$70.04
ADL5324	Driver Amp	400M	14	4G	44	28.9	External	3.3	60m	-
HMC1040	LNA	24G	22	43.5G	22	12	Internal	2.5	70m	$18.26
ADL5606	Driver Amp	1.8G	24.3	2.7G	45.5	30.8	External	5	362m	-
ADL5605	Driver Amp	700M	23	1G	44.2	30.9	External	5	307m	-
ADL5604	Driver Amp	700M	12.2	2.7G	42.2	29.1	External	5	318m	-
ADL5536	Gain Block	20M	20	1G	45	19.6	Internal	-	105m	-
ADL5535	Gain Block	20M	16	1G	45.5	18.9	Internal	-	97m	-
HMC-C079	Low Phase Noise Amp Module	3G	11	8G	25	14	Internal	7	110m	-
HMC963	LNA	6G	22	26.5G	18	10	Internal	3.5	45m	$34.79
HMC962	LNA	7.5G	13	26.5G	23	13	Internal	3.5	70m	$33.22
HMC903LP3E	LNA	6G	18	17G	25	14	Internal	3.5	80m	$20.95
HMC903-Die	LNA	6G	19	18G	27	15	Internal	3.5	90m	$30.52
HMC902LP3E	LNA	5G	19	10G	28	16	Internal	3.5	80m	$21.27
HMC902-Die	LNA	5G	20	10G	28	16	-	3.5	80m	$27.66
HMC863ALC4	Power Amp	22	21.5	26.5	33	24.5	Internal	6	350	-
HMC863A	Power Amp	-	-	-	-	-	-	-	-	-
HMC797APM5E	Power Amp	0	14	22G	41	28	-	10	400m	$149.03
HMC797A-Die	Power Amp	0	15	22	41	29	-	10	400m	-
ADL5601	Gain Block	50M	15	4G	43	19.1	Internal	5	83m	-
ADL5602	Gain Block	50M	19.3	4G	42	19.3	Internal	5	89m	-
HMC-C077	Low Phase Noise Amp Module	1.5G	14	5G	27	17	Internal	8	170m	-
HMC-C076	Low Phase Noise Amp Module	7G	9	11G	33	22	Internal	7	300m	-
HMC-C075	Power Amp Module	-	25	-	42	28	Internal	-	740m	-
HMC-C074	Power Amp Module	10M	13	6G	40	29.5	Internal	-	450m	-
HMC-C072	Low Phase Noise Amp Module	6G	11	12G	34	20	Internal	7	170m	-
HMC-C059	LNA Module	1G	16	12G	29	16	Internal	6	60m	-
HMC-C050	Low Phase Noise Amp Module	2G	13.5	18G	22.5	15	Internal	5	104m	-
HMC-ALH508-Die	LNA	71G	13	86G	-	7	Internal	2.4	30m	$231.35
HMC789	Driver Amp	810M	11	2.8G	42	25	External	5	125m	$4.03
HMC772	LNA	2G	15	12G	25	13	Internal	4	45m	$75.97
HMC754	Gain Block	0M	14.5	1G	38	21	Internal	5	160m	$2.84
HMC753	LNA	1G	17	11G	30	18	Internal	5	55m	$65.42
HMC752	LNA	24G	25	28G	26	13	Internal	3	70m	$25.85
HMC751	LNA	17G	25	27G	25	13	Internal	4	73m	$34.97
HMC741	Gain Block	50M	20	3G	42	18.5	Internal	5	96m	$5.23
HMC740	Gain Block	50M	15	3G	40	18	Internal	5	88m	$5.23
HMC504	LNA	14G	19.5	27G	26	17	Internal	4	90m	$50.82
ADL5523	LNA	400M	21.5	4G	34	21	External	5	60m	-
ADL5521	LNA	400M	20.8	4G	37	21.8	External	5	60m	-
ADL5534	Gain Block	20M	21	500M	40	20.4	Internal	-	98m	-
ADL5321	Driver Amp	2.3G	14	4G	41	25.7	External	3.3	37m	-
HMC-ABH264-Die	Driver Amp	34G	18.5	42G	29	18	Internal	5	120m	$40.07
HMC639	LNA	0.2G	13	4G	38	22	Internal	5	110m	$3.07
HMC636	Gain Block	200M	13	4G	40	22	Internal	5	155m	$3.44
HMC635LC4	Driver Amp, Wideband Distributed Amps	18G	18.5	40G	27	22	Internal	5	280m	$54.84
HMC635-Die	Driver Amp, Wideband Distributed Amps	18G	19.5	40G	27	22	Internal	5	280m	$93.54
HMC634LC4	Driver Amp, Wideband Distributed Amps	5G	21	20G	29	22	Internal	-	180m	$43.96
HMC634-Die	Driver Amp, Wideband Distributed Amps	5G	22	20G	31	23	Internal	5	180m	$42.80
HMC633LC4	Driver Amp, Wideband Distributed Amps	5.5G	30	17G	30	23	Internal	5	180m	$43.74
HMC633-Die	Driver Amp, Wideband Distributed Amps	5G	29	17G	30	23	Internal	5	180m	$32.56
HMC618A	LNA	1.2G	19	2.2G	-	-	External	5	117m	$5.74
HMC599	LNA	50M	14	1G	39	19	Internal	5	120m	$4.78
ADL5320	Driver Amp	400M	13.2	2.7G	42	25.7	External	3.3	47m	-
ADL5531	Gain Block	20M	20.9	500M	41	20.4	Internal	-	100m	-
ADL5570	Gain Block	2.3G	29	2.4G	-	31	-	-	440m	-
ADL5542	Gain Block	50M	18.7	6G	39	18	Internal	5	93m	-
ADL5541	Gain Block	50M	14.7	6G	39.2	16.3	Internal	5	90m	-
HMC-C048	LNA Module	5G	22.5	9G	25	14.8	Internal	12	105m	-
HMC-AUH320-Die	Driver Amp	71G	15	86G	-	15	Internal	4	130m	$65.86
HMC-AUH318-Die	Driver Amp	71G	24	76G	-	17.5	Internal	4	130m	$121.28
HMC-AUH317-Die	Driver Amp	81G	22	86G	-	17.5	Internal	4	160m	$121.28
HMC-AUH312-Die	LNA, Wideband Distributed Amps	0.5G	10	80G	-	13.5	Internal	8	60m	$186.36
HMC-AUH256-Die	Driver Amp	17.5G	21	41G	27	20	Internal	5	295m	$42.50
HMC-AUH249-Die	Driver Amp, Wideband Distributed Amps	0	15	35G	-	21	Internal	5	200m	$125.45
HMC-AUH232-Die	LNA, Wideband Distributed Amps	500M	14	45G	-	16.5	Internal	5	180m	$160.53
HMC-APH634-Die	Driver Amp	81G	12	86G	-	19	Internal	4	240m	$140.07
HMC-APH633-Die	Driver Amp	71G	13	76G	-	20	Internal	4	240m	$140.07
HMC-APH608-Die	Power Amp	22.5G	17	26.5G	38	30	Internal	5	950m	$24.36
HMC-APH596-Die	Driver Amp	16G	17	33G	33	24	Internal	5	400m	$47.51
HMC-APH518-Die	Power Amp	21G	17	24G	39	30.5	Internal	5	950m	$87.17
HMC-APH510-Die	Driver Amp	37G	20	40G	35	26	Internal	5	640m	$16.58
HMC-APH473-Die	Power Amp	37G	15	40G	37	28	Internal	5	1080m	$109.44
HMC-APH462-Die	Power Amp	15G	17	27G	37	29	Internal	5	1440m	-
HMC-APH460-Die	Power Amp	27G	14	31.5G	37	28	Internal	5	900m	$81.76
HMC-APH403-Die	Driver Amp	37G	21	45G	32	23	Internal	5	475m	$52.72
HMC-APH196-Die	Driver Amp	17G	20	30G	31	24	Internal	5	400m	$66.59
HMC-ALH509-Die	LNA	71G	14	86G	-	7	Internal	2	50m	$188.97
HMC-ALH482-Die	LNA, Wideband Distributed Amps	2G	16	22G	-	14	Internal	4	45m	$35.65
HMC-ALH476-Die	LNA	14G	20	27G	-	14	Internal	4	90m	$36.35
HMC-ALH445-Die	LNA	18G	10	40G	-	12	Internal	5	45m	$63.07
HMC-ALH444-Die	LNA	1G	17	12G	28	19	Internal	5	55m	$62.77
HMC-ALH435-Die	LNA	5G	13	20G	25	16	Internal	5	30m	$46.65
HMC-ALH382-Die	LNA	57G	21	65G	-	12	Internal	2.5	64m	$38.07
HMC-ALH376-Die	LNA	35G	12	45G	-	6	Internal	4	87m	$50.66
HMC-ALH369-Die	LNA	24G	17	40G	-	11	Internal	5	66m	$50.65
HMC-ALH364-Die	LNA	24G	21	32G	-	7	Internal	5	68m	$30.21
HMC-ALH313-Die	LNA	27G	20	33G	-	12	Internal	2.5	52m	$41.04
HMC-ALH311-Die	LNA	22G	25	26.5G	-	12	Internal	2.5	54m	$38.84
HMC-ALH310-Die	LNA	37G	22	42G	-	12	Internal	2.5	52m	$43.48
HMC-ALH244-Die	LNA	24G	12	40G	-	13	Internal	4	45m	$59.31
HMC-ALH216-Die	LNA	14G	18	27G	-	14	Internal	4	90m	$46.54
HMC-ALH140-Die	LNA	24G	11.5	40G	-	15	Internal	4	60m	$41.06
HMC-ALH102-Die	LNA, Wideband Distributed Amps	2G	10	20G	-	10	Internal	2	55m	$44.05
HMC-ABH241-Die	Driver Amp	50G	24	66G	25	17	Internal	5	220m	$80.00
HMC-ABH209-Die	Driver Amp	55G	13	65G	25	16	Internal	5	80m	$64.03
HMC659LC5	Power Amp, Wideband Distributed Amps	0	19	15G	35	27.5	Internal	8	300m	$259.15
HMC659-Die	Power Amp, Wideband Distributed Amps	0G	19	15G	-	24	Internal	8	300m	$160.96
HMC609LC4	LNA	2G	20	4G	36.5	21.5	Internal	6	170m	$51.46
HMC609-Die	LNA	2G	20.5	4G	36.5	21	Internal	6	170m	$30.81
HMC608	Driver Amp	9.5G	29	11.5G	33	27	Internal	5	310m	$87.22
HMC606LC5	LNA, Wideband Distributed Amps	2G	12.5	18G	22	13	Internal	-	64m	$97.27
HMC606-Die	LNA, Wideband Distributed Amps	2G	12.5	18G	22	13	Internal	-	64m	$74.71
HMC594LC3B	LNA	2G	10	4G	36	21	Internal	6	100m	$27.24
HMC594-Die	LNA	2G	10	4G	36	21	Internal	6	100m	$21.22
HMC591LP5	Power Amp	6G	18	9.5G	41	33	Internal	7	1340m	$71.16
HMC591-Die	Power Amp	6G	23	10G	43	33	Internal	7	1340m	$54.30
HMC590LP5	Power Amp	6G	21	10G	30.5	21	Internal	7	820m	$48.61
HMC590-Die	Power Amp	6G	25	10G	41	31.5	Internal	7	820m	$43.08
ADL5530	Gain Block	0M	16.8	1G	37	21.8	Internal	-	110m	$1.69
ADL5323	Driver Amp	1.7G	20	2.4G	43.5	28	Internal	5	320m	-
ADL5322	Driver Amp	700M	20	1G	45.3	28	Internal	5	320m	-
HMC-C045	LNA Module	1.8G	26	4.2G	26	15.5	Internal	12	105m	-
HMC-C038	Wideband Distributed Amp Module	2G	9	35G	25	14	Internal	-	92m	-
HMC-C037	Wideband Distributed Amp Module	12G	11	15G	32	26	Internal	-	360m	-
HMC-C036	Wideband Distributed Amp Module	12G	11	15G	32	26	Internal	-	360m	-
HMC-C027	LNA Module	29G	20	36G	22	11	Internal	3	80m	-
HMC-C021	Wideband Distributed Amp Module	21G	15	31G	33	24	Internal	-	215m	-
HMC-C020	Wideband Distributed Amp Module	17G	22	24G	33	24	Internal	-	250m	-
HMC566LP4E	LNA	29G	21	36G	24	12	Internal	3	83m	$30.15
HMC566-Die	LNA	29G	21	36G	23.5	12	Internal	3	80m	$59.60
HMC565LC5	LNA	6G	21	20G	20	10	Internal	3	53m	$32.85
HMC565-Die	LNA	6G	22	20G	20	10	Internal	3	53m	$33.66
HMC564LC4	LNA	7G	17	14G	25	13	Internal	-	51m	$27.06
HMC564-Die	LNA	7G	17	14G	24	12	Internal	3	51m	$27.50
HMC-C026	Wideband Distributed Amp Module	2G	31	20G	33	26	Internal	-	400m	-
HMC-C024	Wideband Distributed Amp Module	20G	16	0.01G	33	24	Internal	12	225m	-
HMC-C023	Wideband Distributed Amp Module	2G	12	20G	25	22	Internal	-	310m	-
HMC-C022	Wideband Distributed Amp Module	2G	13	20G	23	16	Internal	12	75m	-
HMC-C017	Wideband Distributed Amp Module	17G	17.5	27G	26	15	Internal	12	96m	-
HMC-C016	Wideband Distributed Amp Module	17G	21	7G	25	14	Internal	12	93m	-
HMC562-Die	LNA, Wideband Distributed Amps	2G	12.5	35G	27	18	Internal	8	80m	$223.13
HMC559-Die	Power Amp, Wideband Distributed Amps	0	14	20G	36	28	Internal	10	400m	-
HMC549	LNA	40M	5	960M	27	12	Internal	5	120m	$2.48
HMC451LP3	Driver Amp	5G	18	20G	28	19.5	Internal	5	120m	$23.09
HMC451LC3	Driver Amp	5G	19	20G	30	19	Internal	5	114m	$38.92
HMC451-Die	Driver Amp	5G	20	20G	30	20	Internal	5	127m	$28.55
HMC383LC4	Driver Amp	12G	15	30G	25	16	Internal	-	100m	$43.63
HMC383-Die	Driver Amp	12G	16	30G	25	16	Internal	5	100m	$39.56
HMC382	LNA	1.7G	17	2.2G	30	16	Internal	5	67m	$4.88
HMC376	LNA	700M	15	1G	36	21	Internal	5	73m	$6.09
HMC374SC70E	LNA	0.3G	15	3G	35	17	Internal	3.3	75m	$2.95
HMC374	LNA	0.3G	15	3G	37	22	Internal	5	90m	$4.62
HMC3653	Gain Block	7G	15	15G	28	15	Internal	5	44m	$15.38
HMC-C004	Wideband Distributed Amp Module	10M	13	20G	33	23	Internal	12	195m	-
HMC-C003	Wideband Distributed Amp Module	2G	15	20G	34	26	Internal	12	350m	-
HMC-C002	Wideband Distributed Amp Module	2G	12	20G	26.5	18	Internal	12	93m	-
HMC-C001	Wideband Distributed Amp Module	2G	13	20G	25	14	Internal	12	78m	-
HMC519LC4	LNA	18G	14.4	31G	23	11	Internal	3	75m	$47.29
HMC519-Die	LNA	18G	15	31G	23	14	Internal	3	75m	$49.27
HMC518-Die	LNA	20G	15	32G	23	12	Internal	3	65m	$42.46
HMC517LC4	LNA	17G	19	26G	23	12	Internal	3	67m	$39.64
HMC517-Die	LNA	17G	20	26G	23	11	Internal	3	65m	$34.04
HMC516LC5	LNA	9G	20	18G	25	13	Internal	3	65m	$35.75
HMC516-Die	LNA	9G	21	18G	20	13	Internal	3	65m	$27.98
HMC487	Power Amp	9G	20	12G	36	32	Internal	7	1300m	$81.93
HMC480
