产品介绍：伽太科技提供Indie (前德国SiliconRadar)提供24GHz，60GHz，120GHz/122GHz及300GHz收发芯片及开发评估套件
伽太科技 提供Indie（formerly known as Silicon Radar GmbH）24GHz，60GHz，120GHz及300GHz收发芯片及开发评估套件，现货销售
24 GHz Low Noise Amplifier： LNA_024_005
联系：sales@gamtic.com，185 0219 3480
在研产品一览
产品简介 | 频率 | 型号 | 天线类型 | 描述 |
4通道收发器 (2TX / 4RX) | 24 GHz | T2R4_024_020 | 外置 | 角坐标测量 |
单站收发器 | 60 GHz | TRM_060x | 外置 | 集成天线 |
双通道发射 (1TX / 2RX) | 60 GHz | TR2_060x | 外置 | 角坐标测量 |
4通道收发器(4TX / 4RX) | 60 GHz | T4R4_060x | 外置 | 3D探测应用 |
宽带收发器 | 120 GHz | TRA_120_045 | 片上集成 | > 20 GHz 带宽 |
宽带收发器 | 300 GHz | TRA_300_042 | 片上集成 | > 35 GHz 带宽, 配置硅透镜 |
该系列雷达开发评估套件适合初学者，高校科研机构教学或研究应用。即学即用，灵活方便。
联系：sales@gamtic.com，185 0219 3480
Compact Size – Exchangeable Front Ends
SiRad Easy® r4 is an advanced and comprehensive system to evaluate our radar front ends. It is the successor of the SiRad Easy® featuring improved processor power and new connectivity in a smaller form factor. In combination with the included software it provides you with a functional radar system including a large range of functions – well beyond what you find in a simple test board.
Scope of Delivery of StarterKit套件包含：
Reflector to narrow beam and extend range
Radar front end board with TRA_120_002 @ 120 Ghz / TRA_120_045 @ 120 Ghz(20GHz带宽)
（可选配置TRA_300_042, 300GHz太赫兹前端）
Base board with microcontroller
USB cable
Download link for software and documentation
The Starter Kit is a good beginning for your research. You can expand it later with additional components.
Scope of Delivery of EvalKit套件包含
All components from StarterKit (see above)
Radar front end board with TRX_024_046 @ 24 GHz
Breakout board
SiRad Easy® 122GHz雷达开发评估套件
SiRad Easy® is perfectly suited to evaluate all of our TX/RX radar chips. Its small size (100 x 70 mm), rich functionality and open communication protocol make it easy to use. Great for beginners and pros who want to start development and tweak system parameters.
主要特点
programmable FMCW parameters
signal processing
target recognition
web-based GUI
USB communication with PC or over wireless LAN
SiRad Easy includes
1x 122 GHz radar front end (see photo above)
1x 24 GHz radar front end (see lower photo)
1x controller board
1x baseband board with WiFi
1x lens for 122 GHz
The install package is password-protected. Please contact our support.
SiRad Simple
SiRad Simple is perfect to evaluate our 122 GHz radar front end. It has the same functionality as the SiRad Easy but due to its ultra-compact size (40 x 40 mm) it could even be used as a fully functional WiFi-enabled radar sensor with integrated target recognition!
产品联系：伽太科技，sales@gamtic.com，185 0219 3480.
主要特点：
programmable FMCW parameters
signal processing
target recognition
web-based GUI
USB communication with PC or over wireless LAN
SiRad Simple® includes套件包含
1x SiRad Simple® module with WiFi
1x 122 GHz radar front end
1x lens for 122 GHz
Indie（formerly known as Silicon Radar GmbH）芯片型号
300 GHz Transceiver ：TRA_300_042（35GHz带宽） TRA-300-042
24 GHz Low Noise Amplifier： LNA_024_005 ,低噪放芯片 LNA-024-005
