产品介绍:德国Radiometer Physics GmbH( RPG )提供覆盖1.1THz的混频器、倍频器、检波器产品。
Radiometer Physics GmbH提供覆盖毫米波太赫兹频段的倍频器、混频器、检波器、波导器件(耦合器、波导同轴转接器、天线、隔离器)等产品。
产品联系:上海伽太电子科技有限公司
E-mail: sales@gamtic.com, 185 0219 3480
毫米波精密可调衰减器
Product | 频率范围 [GHz] | 波导 | 可调范围 [dB] | 插损 (typ.) [dB] | 型号 |
---|---|---|---|---|---|
WTA 50-75 | 50 - 75 | WR-15 | 0 - 40 | 0.4 | 04700051 |
WTA 60-90 | 60 - 90 | WR-12 | 0 - 40 | 0.4 | 04700052 |
WTA 75-110 | 75 - 110 | WM-2540 (WR-10) | 0 - 40 | 0.4 | 04700053 |
WTA 90-140 | 90 - 140 | WM-2032 (WR-8) | 0 - 40 | 0.4 | 04700054 |
WTA 110-170 | 110 - 170 | WM-1651 (WR-6.5) | 0 - 40 | 0.7 | 04700059 |
WTA 140-220 | 140 - 220 | WM-1295 (WR-5.1) | 0 - 40 | 0.7 | 04700061 |
WTA 170-260 | 170 - 260 | WM-1092 (WR-4.3) | 0 - 40 | 0.7 | 04700063 |
WTA 220-330 | 220 - 330 | WM-864 (WR-3.4) | 0 - 40 | 0.7 | 04700038 |
WTA 260-400 | 260 - 400 | WM-710 | 0 - 40 | 0.7 | 04700033 |
WTA 325-500 | 325 - 500 | WM-570 | 0 - 40 | 1.1 | 04700035 |
WTA 500-750 | 500 - 750 | WM-380 | 0 - 40 | 2.2 | 04700069 |
Millimeterwave Low Noise Amplifier毫米波低噪声放大器
型号 | 频率范围 [GHz] | 波导 | Gain (typ.) [dB] | NF [dB] | P1dB [dBm] | 最大输入功率 [dBm] | Part-no. |
---|---|---|---|---|---|---|---|
V-LNA 50-75 20 5 | 50 - 75 | WR-15 | 19 | 5 | 12 | -5 | 03000023 |
V-LNA 50-75 40 5 | 50 - 75 | WR-15 | 40 | 5 | 12 | -30 | 03000022 |
E-LNA 60-90 14 5 | 60 - 90 | WR-12 | 14 | 5 | 14 | 15 | 03000051 |
E-LNA 60-90 25 5 | 60 - 90 | WR-12 | 25 | 5 | 14 | 0 | 03000059 |
W-LNA 75-110 20 3 | 75 - 110 | WM-2540 (WR-10) | 19 | 3 | -3 | -10 | 03000026 |
W-LNA 75-110 40 3 | 75 - 110 | WM-2540 (WR-10) | 40 | 3 | -3 | -30 | 03000027 |
D-LNA 110-170 15 6 | 110 - 170 | WM-1651 (WR-6.5) | 15 | 6 | -3 | -10 | 03000024 |
D-LNA 110-170 30 6 | 110 - 170 | WM-1651 (WR-6.5) | 30 | 6 | -3 | -30 | 03000025 |
G-LNA 140-220 20 6 | 140 - 220 | WM-1295 (WR-5.1) | 20 | 6 | -3 | -10 | 03000033 |
G-LNA 140-210 20 5 | 140 - 210 | WM-1295 (WR-5.1) | 20 | 5 | -3 | -10 | 03000031 |
LNA 210-260 20 6 | 210 - 260 | WM-1092 (WR-4.3) | 20 | 7 | -3 | -10 | 03000056 |
H-LNA (WR-3.4) | 250 - 330 | WM-864 (WR-3.4) | 22 | 12 | -5 | -10 | 03000017 |
H-LNA (WR-2.8) | 250 - 350 | WM-710 (WR-2.8) | 25 | 12 | -5 | -10 | 03000038 |
Our Sub Harmonic Mixer are based on zero-bias balanced anti-parallel planar Schottky diodes and are suitable for all types of heterodyne detection systems with the advantage of the local oscillator operating at one half of the target frequency.
型号 | 频率 [GHz] | 波导类型 | LO频率 [GHz] | LO波导 | 最小功率 [dBm] | 最大输入功率 [dBm] | Part-no. |
SHM 75-110 | 75 - 110 | WR-10) | 37.5 - 55 | WR-20 | + 10 | + 15 | 02000051 |
SHM 90-140 | 90 - 140 | WR-8 | 45 - 70 | WR-15 | + 10 | + 15 | 02000054 |
SHM 110-170 | 110 - 170 | WR-6.5 | 55 - 85 | WR-12 | + 10 | + 15 | 02000038 |
SHM 140-220 | 140 - 220 | WR-5.1 | 70 - 110 | WR-10 | + 10 | + 15 | 02000019 |
SHM 170-260 | 170 - 260 | WR-4.3 | 85 - 130 | WR-8) | + 10 | + 15 | 02000025 |
SHM 220-330 | 220 - 330 | WR-3.4 | 110 - 165 | WR-6.5 | + 10 | + 15 | 02000018 |
SHM 325-500 | 325 - 500 | WR-2.2 | 162.5 - 250 | WR-4.3 | + 10 | + 15 | 02000055 |
Common specifications for all Subharmonic Mixers in this series.
IF Port: 2.92 mm male/female
Type | 频率 [GHz] | RF Port | 谐波次数 | LO 频率 [GHz] | IF 频率 | Part-No. |
HM 33-50 | 33 - 50 | WR22.4 (UG383/U) | 4 | 8.25 to 12.5 | 5 MHz to 3.2 GHz | 02100032 |
HM 50-75 | 50 - 75 | WR15 (UG385/U) | 4 6 | 12.5 to 18.75 8.33 to 12.5 | 5 MHz to 3.2 GHz | 02100019 |
HM 60-90 | 60 - 90 | WR12 (UG387/UM) | 6 | 10 to 15 | 5 MHz to 3.2 GHz | 02100030 |
HM 75-110 | 75 - 110 | WR10 (UG387/UM) | 7 | 10.7 to 15.7 | 5 MHz to 3.2 GHz | 02100014 |
HM 75-110 | 75 - 110 | WR10 (UG387/UM) | 8 or10 | 9.37 - 13.75 or 7.5 - 11 GHZ | 10 MHz to 2 GHz | 02100044 |
HM 90-140 | 90 - 140 | WR8 (UG387/UM) | 8 10 | 11.25 to 17.5 9 to 14 | 5 MHz to 3.2 GHz | 02100026 |
HM 110-170 | 110 - 170 | WR6 (UG387/UM) | 10 12 | 11 to 17 9.16 to 14,16 | 5 MHz to 3.2 GHz | 02100033 |
HM 140-220 | 140 - 220 | WR5.1 (UG387/UM) | 14 16 | 10 to 15.7 8.75 to 13.75 | 5 MHz to 3.2 GHz | 02100034 |
HM 220-325 | 220 - 325 | WR3.4 (UG387/UM) | 18 22 | 12.22 to 18.05 10 to 14.77 | 5 MHz to 3.2 GHz | 02100028 |
HM 325-500 | 325 - 500 | WR2.2 (UG387/UM) | 36 | 9.3 - 13.88 | 5 MHz to 3.2 GHz | 02100029 |
HM3 325-500 | 325 - 500 | WR2.2 (UG387/UM) | 3 | 108.3 - 166.67 | 5 MHz to 3.2 GHz | 02100022 |
Product | 输出功率[GHz] | 波导 | 输出功率 (typ.) [dBm] | #倍频次数 | Part-no. |
AFM4 45-75 +12 | 45 - 75 | WR-15 | +12 | 4 | 01100061 |
AFM6 60-90 +10 | 60 - 90 | WR-12 | +12 | 6 | 01100035 |
AFM6 75-110 +10 | 75 - 110 | WR-10 | +10 | 6 | 01100083 |
AFM6 70-110 +14 | 70 - 110 | WR-10 | +14 | 6 | 01100065 |
AFM6 80-125 +10 | 80 - 125 | WR-9 | +10 | 6 | 01100034 |
AFM6 80-125 +17 | 80 - 125 | WR-9 | +17 | 6 | 01100066 |
AFM6 90-140 +10 | 90 - 140 | WR-8 | +10 | 6 | 01100041 |
AFM12 110-170 +10 | 110 - 170 | WR-6.5 | +10 | 12 | 01100033 |
Type | RF Port | 输出功率 [dBm (typ.)] | Input Port | 输出频率 [GHz] | 输入频率 [GHz] | 输入功率[dBm] | Part-No. |
FM2 170-260 | WR4.3 | -3 | WR8 | 170 - 260 | 85 - 130 | +11 | 01200025 |
FM2 140-220 | WR5.1 | +3 | WR10 | 140 - 220 GHz | 70 - 110 GHz | +14 | 01200004 |
Type | 频率 [GHz] | RF Port | 功率 [dBm (typ.)] | 输入频率 [GHz] | Input Port | 输入功率 [dBm (typ.)] | Part-No. |
---|---|---|---|---|---|---|---|
FM3 110-170 +10 | 110 - 170 | WR6.5 (UG387/UM) | +10 | 36.6 - 56.6 | WR10 (UG387/UM) | +23 | 01300014 |
FM3 220-330 | 220 - 330 | WR3.4 (UG387/UM) | -3 | 110 - 115 | WR10 (UG387/UM) | +16 | 01300000 |
FM3 325-500 | 325 - 500 | WR2.2 (UG387/UM) | -8 | 108.33 - 166.67 | WR6.5 (UG387/UM) | +14 | 01300012 |
Product | 频率范围 [GHz] | 波导 | VSWR | 插损 (typ.) [dB] | 隔离度 (typ.) [dB] | RF输入功率[dBm] | Part-no. |
WFI 50-75 | 50 - 75 | WR-15 | >1.4:1 | 0.8 | >20 | +20 | 04800024 |
WFI 60-90 | 60 - 90 | WR-12 | >1.4:1 | 1 | >20 | +20 | 04800021 |
WFI 75-110 | 75 - 110 | WM-2540 (WR-10) | >1.4:1 | 1 | >20 | +20 | 04800020 |
WFI 90-140 | 90 - 140 | WM-2032 (WR-8) | >1.4:1 | 1.3 | >20 | +20 | 04800007 |
WFI 110-170 | 110 - 170 | WM-1651 (WR-6.5) | >1.4:1 | 1.5 | >20 | +20 | 04800008 |
WFI 140-220 | 140 - 220 | WM-1295 (WR-5.1) | >1.4:1 | 1.7 | >20 | +20 | 04800022 |
Waveguide Tunable Attenuators波导可调衰减器
